WS-DMX-D4CH DMX512 decoder RGBW LED Controller dimmer Constant Voltage Common Anode DC5V-24V 24A for LED Light Strips/Lamps
Product details
| Management number | 213867491 | Release Date | 2026/04/12 | List Price | $27.63 | Model Number | 213867491 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Low Voltage TransformersProduct Description:Product size: 85*83*25Input/output power supply voltage: DC5V-24VTotal output current: 24AOutput current: maximum 6A per channelChannel: 4 channels 1 groupController: DMX512 3PWorking temperature: -20℃-60℃Weight: 0.1kgBrush frequency: 7.8KHZ2. Function1. Each controller occupies 4 DMX512 addresses.2. The DMX/FUN key switches between DMX512 state or FUN state.3.DMX512 status: DMX512 LED light is onkey(+100) is the DMX512 address plus 100;key(+1) is the DMX512 address plus 1;key(-1) is the DMX512 address minus 1;4.FUN status: FUN light is onkey(+100, Mode) mode plus 1;key(+1, nop) has no effect;key(-1, speed) speed plus 1;Four. status information1. The input voltage of this controller should be as follows. specs, other high voltages will most likely damage it.2. Never connect two wires directly to avoid short circuit.3. The leads should be connected correctly according to the colors in the wiring diagram.
- Low Voltage Transformers
| Model | KOEJDXRQ |
|---|---|
| Brand Name | KOEJDXRQ |
| Part Number | KOEJDXRQ |
| Manufacturer | KOEJDXRQ |
| Specification Met | UL |
